Supports both standard and quick measurement modes. Measures key parameters including toe, camber, caster, steering angle, wheelbase, and track width.
Supports automatic switching of digital targets, reducing the need for physical target installation and storage while improving calibration efficiency.
Supports laser-based automatic centering, parallel positioning, and crossbar height measurement, reducing manual adjustment workload.
The ST13 terminal can wirelessly mirror the screen to a 75-inch display, showing the entire measurement and calibration process in real time.
Covers 50,000+ wheel alignment vehicle models worldwide and supports ADAS calibration for over 95% of vehicle models. The database is continuously updated.
Automatically generates inspection and calibration reports, supports before-and-after data comparison, electronic sharing, and archiving.
| Toe | ±20° |
| Camber | ±10° |
| Caster | ±10° |
| Kingpin Inclination (KPI) | ±20° |
| Maximum Steering Angle | ±35° |
| Wheelbase | 1940–4600 mm |
| Track Width | 1290–1900 mm |
| Rim Diameter (4-Point Wheel Clamp) | 275–640 mm |
| Tire Diameter (3-Point Tire Clamp) | 470–1100 mm |
