Collects data including pressure, temperature, flow rate, and compressor operating status for system diagnostics.
Detects high and low side pressures of the A/C system and supports pressure adjustment.
Recovers and purifies refrigerant from the vehicle's A/C system.
leans A/C piping and removes sludge and impurities.
Removes air and moisture from the A/C system.
Checks the sealing status of the A/C system.
Replenishes PAG/POE compressor oil.
Supports LP, HP, and LP+HP refrigerant charging modes.
| Applicable Refrigerant | R134a or R1238yf (select one) |
| Applicable Vehicle Types | Gasoline vehicles / Hybrid vehicles |
| Refrigerant Recovery Rate | ≥95% |
| Vacuum Pumping Capacity | ≥51 L/min (220V, 50Hz) / ≥57 L/min (110V, 60Hz) |
| Compressor Power | 1/2 HP |
| Dryer Filter Service Life | 60 kg |
| Electronic Scale Accuracy (Main Tank, Oil Bottle) | ±10 g |
| Main Tank Capacity | 0 ~ 12 kg |
| New Oil Bottle Capacity | ≥250 ml (PAG) |
| Used Oil Bottle Capacity | ≥500 ml |
| Pressure Detection Range (HP/TP) | -1 ~ 38 bar |
| Pressure Detection Range (LP) | -1 ~ 18 bar |
| Pressure Detection Accuracy | ±0.5% FS |
| Power Input | AC110V / AC220V 50/60Hz |
