Supports full-system and full-function diagnostics for new energy vehicles including code reading, code clearing, live data reading, actuation tests, and special functions. Supports remote collaboration, super remote diagnosis, and trial feedback functions.
Supports battery pack testing for passenger vehicles, commercial vehicles, and battery brands. Reads SOC/SOH, cell/module voltage, temperature, battery pack status, and fault information. Automatically calculates key metrics such as total voltage, voltage differential, and highest/lowest voltage, with automatic anomaly data labeling.
Supports offline testing for DC-DC converters, OBC (on-board chargers), A/C compressors, 48V mild-hybrid components, and more. Supports maintenance light reset, throttle matching, brake pad replacement, steering angle reset, immobilizer/anti-theft matching, ABS bleeding, injector coding, DPF regeneration, sunroof initialization, transmission matching, and more.
Supports vehicle anti-theft matching, anti-theft chip read/write, anti-theft ECU read/write, key matching, and more.
Supports ADAS system calibration for a wide range of European, American, Asian, and Chinese vehicle models. Compatible with ADAS PRO+, ADAS MOBILE, ADAS LITE, ADAS RADAR 3IN1, and other devices.
Supports balancing test, wireless balancing, charge-discharge, balancing charge-discharge, air tightness test, oscilloscope, multimeter, voltmeter, fast charging tester, digital power supply, insulation test, current clamp, and endoscope.
| Display | 13.3 inches (1920 × 1080) |
| CPU | 2.0GHz Octa-core |
| Memory | 8GB |
| Storage | 256GB |
| System | AAOS (Android 10) |
| Wi-Fi | 2.4GHz/5GHz Dual-band Dual Wi-Fi |
| Camera | Front 8MP, Rear 13MP |
| Battery | 13600mAh / 3.8V |
| Interfaces | USB, Type-C, DC-IN, Mini HDMI |
| Communication | Wi-Fi, Bluetooth, USB |
